Teaching AI to Write Datto RMM Components

If you’ve ever asked an AI assistant to write a Datto RMM monitor script, you’ve probably gotten something that looks right but fails silently in production. It uses Write-Output instead of Write-Host. It’s missing the diagnostic markers. The exit codes are wrong. The AI doesn’t know what it doesn’t know about Datto’s quirks.

So I built an agent skill that fixes this — a structured knowledge pack that teaches AI coding assistants how Datto RMM components actually work.

GitHub: ompster/datto-rmm-agent-skill

What’s an Agent Skill?

An agent skill is a set of reference documents, templates, and validation scripts that an AI assistant loads when it detects a relevant task. Think of it as giving your AI a specialised textbook before asking it to do the work.

When you ask your AI to “write a Datto RMM monitor for disk space”, the skill kicks in and ensures the output follows the actual Datto contracts — not the AI’s best guess at what they might be.

The Problem

Datto RMM has some non-obvious requirements that AI assistants consistently get wrong:

Monitor output contract. Monitors must emit specific markers that Datto’s parser expects:

<-Start Diagnostic->
Checking disk space on C:\
Free space: 45.2 GB (23% free)
Threshold: 10%
<-End Diagnostic->
<-Start Result->
Status=OK: Disk space healthy (23% free)
<-End Result->

Miss these markers? Your monitor shows “no data” in the Datto dashboard. No errors, no warnings — just silence.

Write-Host, not Write-Output. This catches everyone. In normal PowerShell, Write-Output is the standard. In Datto monitors, it goes to the pipeline and gets eaten. Write-Host is the only output method that works reliably.

Exit codes matter differently. Components use 0/1/2 (success/warning/error). Monitors use 0 for healthy and non-zero for alert. Applications recognise 3010 (reboot required). Get these wrong and your alerting fires backwards.

The 3-second wall. Monitors have a hard timeout of under 3 seconds. That Get-WmiObject Win32_Product call you’re using for software detection? It takes 30+ seconds and triggers MSI reconfiguration as a side effect. Don’t use it.

What’s in the Skill

Reference Documents

Monitor Contract — The exact marker format, output variable rules, helper function patterns, and common mistakes
Component Patterns — Download best practices (TLS 1.2, hash validation, BITS for large files), file attachments, environment variables, error handling
Function Reference — Full documentation of the DattoRMM-toolkit functions with signatures and examples
PowerShell Pitfalls — PS 5.1 gotchas that break scripts in production (ASCII encoding, ForEach-Object scoping, SYSTEM context quirks)

Templates

Ready-to-use starting points for both components and monitors, with the correct patterns already in place:

# Monitor template includes embedded helpers
function Write-MonitorAlert {
    param([string]$Message)
    Write-Host '<-End Diagnostic->'
    Write-Host '<-Start Result->'
    Write-Host "Status=$Message"
    Write-Host '<-End Result->'
    exit 1
}

function Write-MonitorSuccess {
    param([string]$Message)
    Write-Host '<-End Diagnostic->'
    Write-Host '<-Start Result->'
    Write-Host "Status=$Message"
    Write-Host '<-End Result->'
    exit 0
}

Validation Script

A PowerShell script that checks components for common issues before deployment:

Non-ASCII characters (PS 5.1 will mangle these)
Write-Output usage in monitors (will cause “no data”)
Missing diagnostic/result markers
Missing TLS 1.2 enforcement in download scripts
Win32_Product usage (slow, side effects)
Missing exit codes

.\validate-component.ps1 -Path "my-monitor.ps1" -Type Monitor

Component Types at a Glance

Type	Timeout	Exit Codes	Notes
Applications	30 min	0=success, 3010=reboot	Convertible to Scripts
Scripts	Flexible	0=success, 1=warn, 2=error	Convertible to Applications
Monitors	Under 3 sec	0=healthy, non-zero=alert	Immutable once created

The big gotcha: Monitor category can never be changed after creation. Plan accordingly.

Key Rules the Skill Enforces

Pure ASCII in .ps1 files. PowerShell 5.1 mangles non-ASCII characters depending on system code page. No emoji, no em dashes, no curly quotes.
Write-Host only for monitors. Write-Output goes to the pipeline and Datto’s monitor parser never sees it.
TLS 1.2 for downloads. Older Windows systems default to TLS 1.0/1.1 which most CDNs reject. One line fixes it:
Terminal window
```
[Net.ServicePointManager]::SecurityProtocol = [Net.SecurityProtocolType]::Tls12
```
Registry-based software detection. Query the uninstall keys directly (both 32-bit and 64-bit). Never Win32_Product.
File attachments by filename. Datto places attached files in the working directory. Reference by name, not absolute path.
SYSTEM context awareness. Components run as NT AUTHORITY\SYSTEM. User-specific operations need Invoke-AsLoggedOnUser.

Using It

With an AI Agent (OpenClaw, Codex, Claude Code)

Drop the skill folder into your agent’s skills directory. The agent auto-detects it when you ask about Datto RMM components:

"Write a Datto RMM monitor that checks if OneDrive is syncing"
"Create a component to install Chrome silently"
"Review this monitor script for issues"

The agent reads the skill, loads the relevant references, and produces output that follows the actual Datto contracts.

As a Human Reference

Even without an AI agent, the reference docs are solid documentation for anyone building Datto RMM components. The monitor contract doc alone would have saved me hours of debugging “no data” issues.

This skill is built on top of the DattoRMM-toolkit — a PowerShell module with shared functions for logging, exit codes, UDF management, user context operations, and more. The skill teaches AI agents how to use the toolkit effectively.
